MODULAR RESERVOIR SYSTEM

rainwater collection and infiltration

>200

qualified specialists
>10000m³

of reservoirs produced
>300

completed projects
>250

cities of operation

WHY IS THIS SYSTEM ESSENTIAL?

PREVENTS FLOODING OF INDUSTRIAL AND OTHER FACILITIES
REDUCES LOAD ON SEWER SYSTEMS AND TREATMENT PLANTS
INFILTERS WATER INTO SOIL
COLLECTS RAINWATER FOR REUSE
PROTECTS AGAINST PEAK FLOW DISCHARGES INTO SEWER SYSTEM

OUR ADVANTAGES

Quick installation

No heavy machinery or large installation crews required.
High storage capacity

The system can be filled with water up to 95% capacity, significantly reducing earthwork.
Versatility

Suitable for water storage tanks, equalization basins, flow-control reservoirs, and infiltration facilities.
Long service life

Modules are made of corrosion-resistant polypropylene with a lifespan of up to 50 years.
Reliability

Design load capacity per module:
Horizontal – up to 90 kPa
Vertical – up to 425 kPa
Easy maintenance

Modular design allows full access to all system components for inspection, video monitoring, and flushing.
Cost-efficient logistics

Modules nest compactly inside each other, reducing warehouse storage and transportation space – cutting your logistics costs.

EFFICIENT LOGISTICS PRINCIPLE

Modules nest compactly inside each other, fully utilizing truck space with a capacity of up to 350 m².
Each pallet holds 5.27 m³ of future reservoir capacity.

This technology reduces warehouse storage and transportation space by four times compared to alternatives, minimizing your costs.
A single truckload of our modules equals four truckloads of alternative systems.

COLLECTION SYSTEM

for stormwater collection and flow regulation

ENABLES UTILIZATION OF RAINWATER FOR INDUSTRIAL USE AND IRRIGATION
PREVENTS PEAK FLOW DISCHARGES INTO STORMWATER SEWER SYSTEM
REDUCES REQUIRED CAPACITY OF TREATMENT FACILITIES

FILTRATION SYSTEM

for stormwater infiltration

ELIMINATES THE NEED FOR EXTENSIVE STORMWATER SEWER SYSTEM CONSTRUCTION
REDUCES LOAD ON SEWER SYSTEMS AND STORMWATER TREATMENT PLANTS
SUPPORTS CONSISTENT REPLENISHMENT OF UNDERGROUND FRESHWATER RESERVES

MODULE INSTALLATION

inside the reservoir

ASSEMBLY PRINCIPLE

8 simple steps

Side panel

Base for covering materials and protection against horizontal loads

Connector and top cover

Components for interconnecting tiers and leveling the reservoir's upper edge

VORTEX SEPARATOR

for reducing system load

SYSTEM CAPACITY

SYSTEM ACCESS

SYSTEM CLEANING

The process begins with inserting a camera probe into the reservoir interior through the well.
Next, a pressurized hose with multi-directional nozzle is inserted for water injection.

MODULAR RESERVOIR SYSTEM

THE SYSTEM UPPER LEVEL IS ENCLOSED WITH SPECIAL COVERS, ASSEMBLED IN GROUPS OF FOUR TO FORM A SINGLE STRUCTURAL UNIT.
WHEN REQUIRED AND DEPENDING ON SYSTEM CONFIGURATION, MODULAR ELEMENTS CAN BE DIVIDED INTO HALVES.
INDIVIDUAL SYSTEM LEVELS ARE SECURED TOGETHER WITH INTERLOCKING CONNECTORS. SIMPLY STACK ONE MODULE ON TOP OF ANOTHER AND PRESS GENTLY UNTIL AN AUDIBLE CLICK IS HEARD.
UNLIKE COMPARABLE SYSTEMS, OUR DESIGN PERMITS VIDEO INSPECTION AND FLUSHING OF ALL RESERVOIR LEVELS IN ANY DIRECTION.
THE MODULAR FRAMEWORK OCCUPIES JUST 5% OF THE CONSTRUCTION VOLUME, LEAVING 95% AVAILABLE FOR WATER COLLECTION.
THE SYSTEM IS MANUFACTURED FROM POLYPROPYLENE SUITABLE FOR FUTURE REPROCESSING.
